Mahr Digimar 816 CL — Vertical digitizing & coordinating measuring Machines

Height measuring instrument + marble table

Measuring range mm: 0 > 600 mm
Resolution:nbsp;0.001 mm / 0.01 mm
Error limit:nbsp;(2.8+L/300) L in mm
Repeatability bores:nbsp;3 µm
Repeatability plane: 2 µm
Perpendicularity error in µm: 20 µm
Measuring force (N):nbsp;1.0 +/- 0.2 N
Product weight: 30 kg
Standard Data interface:nbsp;Opto RS-232C / USB / wireless

> Excellent accuracy and reliabilty due to the optical incremental measurement system with the double reader head
> Dynamic probing system enabling high repeatability
> Air bearings system for light and smooth movement
> Precise measuring head on stainlees steel guideways
> Motorized measuring carriage simplifies measurement runs
> Temperature compensation with an integrated temperature sensor
> Probe constant remains after the instrument is switched off
> Integrated rechargeable battery with a long operating time span for power source independent measurement

Operating and display unit
> Easy to read backlit graphic LCD
> Clear function keys
> Language-neutral operator guidance with self-explanatory symbols
> Possible to set additional zero points
> Memory can store up to 99 measured values
